Description
FEATURES:
84% energy efficiency
- Geyser can function on low and high-water pressure
- Compatible with mixer taps
- Flame failure safety device (FFD)
- LCD temperature display
- Requires no electricity – flame ignition and geyser functions are battery operated (optional solar battery available)
- Pressure Relief Protection (to function effectively, the valve must be set to your water pressure)
SPECIFICATIONS:
Max gas pressure 2.8kPa
Max gas consumption 2.65 kg / hour
Rated Input 32Kw
Water pressure 20-500 kPa
Min water output 3L /min
Max water output 16L / min
Minimum cylinder size = 19kg
Minimum regulator size = 4kg/hr
A GUIDE LINE OF SHOWERING TEMPERATURES:
Body temperature: 35-37°C.
Summer time comfortable showering temperatures: 35-38°C.
Warm shower in winter: 39°C.
Hot showering temperature in winter 42°C (most preferred showering temperature).
Very hot showering temperature in winter: 44°C.
For a bath temperature in winter: 48-50°C.
DIMENSIONS:
Unit weight 13.2 Kg
Packaged weight 15.5 Kg
Unit size 745 x 425 x 230 mm
Packaged size 865 x 485 x 270 mm
OPTIONAL EXTRAS:
FLUE:
The gas geyser should be installed with a 110mm solid or flexible flue and the appliance should be close to the flue
termination to avoid unnecessary elbows and excessive flue length. A flue cowl should be used if installed outdoors to prevent rain from entering the geyser.
COVERS:
If a Gas Geyser is installed (OUTSIDE) must be installed with a weather box to protect the appliance against extreme weather and damage. These boxes are designed to allow the hot air that is released by the unit to escape so that they do not over heat and cut out. In extreme weather areas we recommend using a flue. If your geyser uses a flue then you will need a cover that has a flue roof.
FEATURES:
Rust proof
Easy to ship and assemble (flat packed)
Easy to install (use our template for quick installations)
Easy to paint – Galvanised steel
GAS GEYSER SIZES DEPEND ON THE FLOW RATE PER MINUTE. FLOW RATE, OR FLOW DEMAND, IS THE TOTAL NUMBER OF LITERS PER MINUTE THAT YOUR TAPS OR OUTLETS USE WHEN THEY’RE TURNED ON. YOU CAN CALCULATE YOUR FLOW RATE USING THE SIMPLE BUCKET TEST.
CALCULATE YOUR FLOW RATE BY DOING THE BUCKET TEST!!
- Place a bucket under your largest cold-water tap.
- Turn to full and run for 30 seconds.
- Measure how much water is in the bucket.
- Multiply that measurement by 2 to find your flow rate in litres per minute.
- For multiple use models repeat this process for each tap but make sure that all your taps are running at the same time.
- Add all the flow rates together for your overall flow demand.
