Description
APPLICATIONS:
Camper van Conversions: Ideal for larger van conversions like the VW Crafter, Mercedes Sprinter, or Ducato. Its tall, slim design allows it to fit into kitchen cabinetry while providing enough storage for several weeks of travel.
Marine & Boats: Due to its efficient compressor and ability to handle high ambient temperatures, it is used in marine vessels where 12V/24V power is standard.
Off-Grid Living: Suitable for small cabins, tiny homes, or garden offices where mains power is unavailable. It can run effectively off solar panels or portable power stations.
RV & Motorhome Upgrades: Frequently used as a more efficient and reliable replacement for older 3-way absorption fridges that struggle in hot weather.
SPECIALIZED USE CASES:
Emergency Home Backup: Useful during load shedding or blackouts to keep essential food and medications (like insulin) cold.
Mobile Business: Often fitted into horse trailers, food trucks, or mobile work offices for staff refrigeration.
Overlanding Expeditions: Its robust construction and battery protection make it suitable for 4×4 expedition vehicles where it can withstand bumpy road conditions
FEATURES:
Dual-Zone Functionality: Features a separate freezer compartment that can be removed to turn the entire unit into a large refrigerator.
Smart Controls: Equipped with a digital LED display and Bluetooth connectivity for remote monitoring via the Alpicool App.
Battery Protection: Includes a 3-stage battery protection system (Low, Medium, High) to prevent draining the vehicle’s starter battery.
Installation Flexibility: The door hinges are reversible, allowing it to open from either the left or right to suit different van layouts.
Quiet Operation: Noise levels are rated below 45dB, making it suitable for sleeping in close proximity.
Storage: Includes a removable freezer compartment, adjustable wire shelves, a large crisper drawer, and door bins.
Build: Features a reversible door (hinges can be moved to either side) and a secure door latch.
Specifications:
Voltage Support: Dual power inputs for 12V/24V DC and 100–240V AC (AC adapter often included).
Power Input: Rated at 80W peak (some variants reaching 120W).
Average Consumption: Approximately 1.2 Ah/h at +25°C ambient temperature.
Temperature Range:
Fridge: 0°C to +8°C.
Freezer: -20°C to -12°C.
Compressor: High-efficiency DC compressor (often LG branded) with R134a refrigerant.
Battery Protection: 3-stage intelligent system (Low/Medium/High) to prevent total vehicle battery drain.
WARRANTY:
Limited 1 Year Warranty.
DIMENSIONS:
- PACKAGING DIMENSIONS: 1040 mm (H) x 567 mm (W) x 507 mm (D).
- PACKGING WEIGHT: 27.5 kg
Total Volume: 90 Litres (some models listed up to 93.4L).
External Dimensions: 418mm (L) x 485–504mm (W) x 975mm (H)
Internal Storage: The unit provides roughly 90L of total capacity, with a freezer section approximately 430 mm high and 500 mm wide.
Fridge Area: 82L of usable space for chilled items.
Freezer Area: 9.4L, typically located at the top.
Important: Ensure at least 50 mm of clearance at the rear and top to maintain optimal cooling performance and prevent the compressor from overheating
WHATS IN THE BOX?
Alpicool CR90 Unit: The 90-litre upright fridge with a pre-installed reversible door.
Removable Freezer Compartment: An internal 9.4L sub-section that can be taken out to create a single large 90L fridge zone.
INTERNAL STORAGE SET:
Adjustable Wire Shelves: Movable shelves to customize the internal layout.
Crisper Drawer: A large bottom drawer for salads and fresh produce.
Door Bins: Removable plastic bins for bottles and smaller.
Power & Connectivity:
DC Power Cable: A 12V/24V cable for connection to your vehicle’s cigarette lighter or leisure battery system.
AC Power Adapter: A dedicated 100-240V power brick for plugging the unit into standard household wall outlets.
When you unbox the Alpicool CR90 , you will typically find the main unit pre-assembled with its internal storage components and the necessary power cables for both mobile and static use.
Accessories & Documentation:
Ice Cube Tray: Usually included within the freezer section.
User Manual: Detailed instructions for installation, temperature control, and app.
