Description
Features:
- Free stainless steel vent cover included
- LPGSA approved
- 36-month guarantee
- Designed & manufactured in South Africa
- ISO 9001-approved factory
- High-grade stainless steel
- Easy to use
- Stainless steel hinged dust cover included
- Stainless steel drip tray included
- Suitable for indoor & outdoor applications
- Requires a gas installer for installation(See ‘Additional information’ for technical data)
Important when purchasing a Hob Grill:
- The countertop and cabinetry housing the Hob Grill must be lined with fire-retardant materials (e.g., ceramic blanket or vermiculite).
- This product requires Ventilation holes to be added to the cabinet housing the unit, allowing for sufficient airflow to the burners. A free stainless steel vent door cover is included
- This Product will need a hinged door built into the cabinet housing the unit, to provide access to the Drip-Tray.
IMPORTANT WHEN PURCHASING A HOB GRILL:
- The countertop and cabinetry housing the Hob Grill must be lined with fire-retardant materials (e.g., ceramic blanket or vermiculite).
- This product requires Ventilation panels to be added to the cabinet housing the unit, allowing for sufficient airflow to the burners.
- This Product will need a hinged door built into the cabinet housing the unit, to provide access to the Drip-Tray.
DIMENSIONS:
Product Weight: 28 kg
Product Dimensions: 790 × 480 × 230mm
Assembled Size: 775mm x 450mm x 220mm
Grilling Area: 519mm x 350mm
Hole cut out size: 725 x 410 x 250
Packaging Weight: 30,5kg
Package Dimensions: 820 × 500 × 250mm
ADDITIONAL INFORMATION:
Stainless Steel Grades: Inland Grade, Coastal Grade
Gas Type: LPG, Natural Gas
Heat Dispersion Technology
Hot Rock, Flame Tamers
Operating Pressure: 2.8 kPa
kW input: 3.9 kW/h per burner
BTU: 13307 BTU/h per burner
Gas Consumption: 0.28 KG/h per burner on high
Ignition Type; Piezo Ignitor
Grid Technology: 6mm stainless steel bar (dishwasher safe)
CABINETRY SPECIFICATIONS:
The countertop and cabinetry housing the Hob Grill must be lined with fire retardant materials
VENTILATION REQUIREMENTS:
This product requires Ventilation panels to be added to the cabinet housing the unit
INSTALLATION INSTRUCTIONS:
Provision must be made in the cabinet housing the unit, to provide access to the Drip-Tray.
The Hob Grill is designed to be dropped into a counter top, with the appropriate amount of crossflow ventilation designed into the cabinetry, and a door to access the drip tray.
The counter top and cabinetry housing the Hob Grill should be lined with fire retardant materials (e.g., ceramic blanket or vermiculite).
Take care to ensure your permanent Gas Installation is fitted with Copper Piping for a minimum of 1 meter leading to the inlet of the Hob Grill.
