Description

FEATURES:

LPGSA approved.

Ignition: Piezo Spark.

24-month guarantee.

Ceramic Ash: 2kg.

Gas Logs: 5.

Low maintenance.

Easy to use.

Clean & efficient burning system.

Requires a gas installer for installation.

Needs to be placed into a suitable heat-resistant structure.



BURNER FINISH OPTIONS:

Ceramic Logs.

Fire Glass:

-Black Ceramic Ash



SPECIFICATIONS:

Assembled Size: 424mm (diameter).

Operating pressure: 2,8 kPa.

Min Regulator size: 4 kg/hr.

Max. gas consumption: 0.82 kg/hr.

Max. Mj input: 41 Mj/hr.

Max. kW input: 11.4 kW/hr.

Gas inlet connection: Ø8mm comp.

ODS (Pilot jet): min 18.5% O2.

DIMENSIONS:

Product Dimensions: 424mm(L) X 424mm(W) X 150mm(H)

Product Weight: 9.6Kg

Shipping Dimensions: 460mm(L) X 460mm(W) X 200mm(H)

Shipping Weight: 10Kg.



MORE INFORMATION:

BUILDING INSTRUCTIONS:

Avoid areas where there are strong draughts, which may be generated by narrow walkways, as excessive wind could affect the correct working of the burner.

MINIMUM CLEARANCES:

Above the fire pit 1500 mm

To the sides of the fire pit 800 mm

Underneath the fire pit 300 mm
