Description
Brand: Intel
Series: 14th Gen Raptor Lake-S
Model: BX8071514700
ESSENTIALS:
Vertical Segment: Desktop
Lithography: Intel 7
Core Arrangement: 8 Performance Cores, 12 Efficiency Cores
Cores: 20
Threads: 28
Performance-core Max Turbo Frequency : 5.40GHz
Efficient-core Max Turbo Frequency: 4.20GHz
Performance-core Base Frequency: 2.10GHz
Efficient-core Base Frequency: 1.50GHz
Cache: 33 MB Intel Smart Cache
Processor Base Power: 65W
Maximum Turbo Power: 219W
TJUNCTION: 100°C
MEMORY
Max Memory Supported: 192 GB
Memory Types: Up to DDR5 5600MT/s, Up to DDR4 3200MT/s
Max Number of Memory Channels: 2
Max Memory Bandwidth: 89.6GB/s
GRAPHICS:
Processor Graphics: Intel UHD Graphics 770
Graphics Base Frequency: 300 MHz
Graphics Max Dynamic Frequency: 1.50GHz
Graphics Output: DisplayPort 1.4a, HDMI 2.1
Execution Units: 32
Max Resolution (HDMI): 4096 x 2160 @ 60Hz
Max Resolution (DP): 7680 x 4320 @ 60Hz
API Support: DirectX 12.1, OpenGL 4.5, OpenCL 3.0, Vulkan
Multi-Format Codec Engines: 2
Intel Quick Sync Video Support: Yes
Intel Clear Video HD Technology Support: Yes
Number of Displays Supported: 4
EXPANSION
Direct Media Interface (DMI) Revision: 4
Max Number of DMI Lanes: 8
Scalability: Single socket
PCI Express Revision: 5.0 and 4.0
PCI Express Configurations: Up to 1×16 plus 4 lanes OR 2×8 plus 4 lanes
Max Number of PCI Express Lanes: 20
GENERAL
Advanced Features: Intel Gaussian & Neural Accelerator 3.0
INTEL THREAD DIRECTOR
Intel Deep Learning Boost (Intel DL Boost).
Intel Speed Shift Technology.
Intel Turbo Boost Technology 2.0.
Intel Hyper-Threading Technology.
Intel 64.
64-bit Instruction Set.
Intel SSE4.1, Intel SSE4.2, Intel AVX2 Instruction Set Extensions.
Idle States.
Enhanced Intel Speed Step Technology.
Thermal Monitoring Technologies.
Intel Volume Management Device (VMD).
SECURITY & RELIABILITY FEATURES:
Intel Standard Manageability (ISM).
Intel Control-Flow Enforcement Technology.
Intel AES New Instructions.
Secure Key.
Intel OS Guard.
Intel Trusted Execution Technology.
Execute Disable Bit.
Intel Boot Guard.
Mode-based Execute Control (MBEC).
Intel Stable IT Platform Program (SIPP).
Intel Virtualization Technology with Redirect Protection (VT-rp).
Intel Virtualization Technology (VT-x).
Intel Virtualization Technology for Directed I/O (VT-d).
Intel VT-x with Extended Page Tables (EPT).
Operating System Support: Windows 10 64-bit
Windows 11: 64-bit
Linux x86-64
Linux x86-64
WARRANTY INFORMATION
Warranty: 3 Year Warranty
